Pick the kit that fits your car, then follow the 14 steps — built for first-time DIYers and working pros.

25,000+

Paint Jobs Completed

All-In-One

Everything Included

Step-by-Step

Video Support

Painting a Vehicle as a DIY Customer — Using TSS Car Paint Kits

After you choose the color you want to paint your project, you just need to answer 4 easy questions and we handle the rest! We have kits for any project size — motorcycles, coupes, sedans, SUVs, and even trucks. We have kits for any project type — metal up restorations, projects that need light body work, or even scuff & shoots!

Using spray cans instead? Wheels, calipers, bikes and spot repairs have their own guides → Spray can guides

What to Expect When Purchasing a TSS Car Paint Kit — Featuring Tommy on MotorTrend's Motorhead Garage

What to Expect When Purchasing a TSS Car Paint Kit

In this video Tommy (TSS' owner) talks with Motorhead Garage on MotorTrend about all of the key benefits of our complete car kits! After you choose the color you want to paint your project, you just need to answer 4 easy questions and we handle the rest!

Kits for any project size: Motorcycles, Coupes, Sedans, SUVs, and even trucks!
Kits for any project type: Metal up restoration, projects that need light body work, or even scuff & shoots!

14 Steps to a Professional Paint Job

  1. Complete Prep Work

    Follow the directions in the videos above to complete your prep, body work, primer, and sanding.

  2. Block Sand Exterior

    Block sand your exterior panels with 320 grit sandpaper & scuff your door jambs, engine bay, intricate areas with a red scuff pad.

  3. Clean Surfaces

    Blow off all dust (outside - NOT in your paint area) & wipe down with a wax & grease remover.

  4. Door Jambs & Engine Bay

    If applicable: Complete steps 5-12 on your door jambs & engine bay. Wait 24hrs before moving on to the exterior.

  5. Re-Mask Exterior

    Re-Mask to paint the exterior of the project in your paint area & wipe down with an anti static wax & grease remover.

  6. Spray DTM Primer

    Mix & spray (1) medium wet coat of AP-7541 DTM primer mixed 4:1:2 using a 1.4 needle spray gun, over the clean, sanded/scuffed surface.

    Shop AP-7541 DTM Primer →
  7. Wait for Sealer to Dry

    After the Sealer is 100% dry to the touch (no wet areas anywhere), wait at least 1 hour before proceeding.

    💡 Don't rush this step. Full drying prevents adhesion issues later.
  8. Apply Basecoat

    Mix & spray your basecoat directly over the Sealer (Most colors require 2-4 coats for coverage/effect).

  9. Flash Dry Between Coats

    Wait until the basecoat is flashed/dry before recoating (Dry to the touch).

  10. Cure Final Basecoat

    After the final base coat is 100% dry to the touch (no wet areas anywhere), wait 45 mins before proceeding.

  11. Apply Clearcoat

    Mix & Spray 2-3 coats of AC-4521 directly over the basecoat. Recoat when the previous coat is fingerprinting when touched.

  12. Cure Clearcoat

    Let cure 12 hours in a warm (70°F+) ventilated area (keep fan on to evacuate all solvents).

  13. Unmask & Assemble

    If wet sanding and buffing - leave masked for that process. Otherwise, unmask & assemble!

  14. Enjoy Your Paint Job!

    Now Go Enjoy Your Paint Job!

Technical Data Sheets (TDS)

Read the TDS for every product in your kit before starting. These sheets have the exact mix ratios, dry times, recoat windows, and application specs.

Kit Products:

AP-7541 DTM Primer/Sealer TDS

AC-4521 HS Glamour Clearcoat TDS

Alpha Basecoat TDS (Custom, OEMatch, OEMatch+)

TrueFill Polyester Body Filler TDS

Other Useful TDS:

AC-6021 UHS Euro Clearcoat TDS · Candy/Pearl Carrier TDS · Candy Concentrates TDS · AP-5021 Epoxy Primer TDS

Full TDS hub: thespraysource.com/pages/tds

How To Build Your DIY Vehicle Paint Kit — Step by Step
What Size Kit Should I Choose?

What Size Kit Should I Choose?

Not sure exactly what size you need for your project? Tommy answers some questions about this and we have an easy to follow guide below!

Tip: Still not sure? It's always better to size UP! More product guarantees you will have more than enough to complete the project which is MUCH better than running out before completing the job.

What 'Project Type' Do I Choose?

What 'Project Type' Do I Choose?

In this video we go over the different type of projects and the different components and steps needed for each. No matter the scope of your project — we have a kit for you!

Metal Up: A project being stripped to bare metal and restored all the way up.

Light Body Work: A project overall in good shape but needing some body work; you'll need to spot prime those areas before painting.

Scuff & Shoot: A project in mint condition that doesn't need body work. Usually newer vehicles OR budget/quick projects where you don't care about spraying over the current condition. The current finish just gets "scuffed" and then painted.

What's Being Painted?

What's Being Painted?

In this video we also go over what each term means when we ask 'What's Being Painted'.

Full Color Change: Changing the entire color of your vehicle's exterior, door jambs, engine bay, etc.

Exterior Panels Only: ONLY painting the exterior. NOT the door jambs, engine bay, etc.

Why Does Temperature Matter?

Why Does Temperature Matter?

The temperature you choose for your Car Paint Kit is actually really important! Most people who are not a professional painter have no idea that the speed/temperature of your hardeners, reducers, and clearcoats are make or break for your project's longevity & final finish.

That being said, DON'T WORRY! We have your back! Just choose the approximate temperature you plan to be painting in! This means — think about when and where you plan to be spraying. What time of year, what time of day, the building/structure you plan to paint in, etc.

Most projects are sprayed in 71–90°F.

Still more questions? Finish this video for a few extra items you may need, then use the chat at the bottom right or call/text 508-316-9868.
Want to See the Color in Person Before Committing?

Want to See the Color in Person Before Committing?

It's important to see a sprayed out sample of the chosen color BEFORE deciding to purchase a complete Car Paint Kit. Seeing them in person, under different lighting and angles will make you 100% sure you are ready to paint!

Join The Spray Source Paint Community

Thousands of painters share their builds, ask questions, and swap tips in our TSS Facebook Community Group. Whether you're planning your first project or your fiftieth, the community has your back. Tommy and the TSS team are active in the group answering questions, sharing new content, and featuring customer builds.

Follow us on Facebook · Instagram · YouTube · TikTok

Download the Free Cheat Sheet

All the steps, mix ratios, spray gun settings, and pro tips on one handy reference card. Thousands of painters keep this pinned in their garage. Download the PDF free or order a paper copy shipped with your next order.

Vehicle Paint Kit FAQ

Which kit size do I need?

Motorcycle/bike: 1–2 quarts basecoat + 1 quart clear. Small car: 3–4 quarts + 1 gallon clear. Medium car: 4–5 quarts + 1–1.5 gallons clear. Large car/truck/SUV: 5–8 quarts + 1.5–2 gallons clear. Single panel: 1 pint–1 quart + 1 quart clear. When in doubt, always size UP — more product is much better than running out mid-project.

Ask the paint expert about this →
What's included in a car paint kit?

Every kit includes: AP-7541 DTM Primer/Sealer (gray, black, or white), your chosen basecoat color, urethane reducer matched to your spray temperature, activator/hardener for primer and clearcoat, Alpha 2K clearcoat, and step-by-step instructions. 3-stage colors also include the correct undercoat. Optional add-ons: masking tape/paper, body filler, spray glaze, OptiGrit sandpaper, scuff pads, wax & grease remover, and tack cloths.

Ask the paint expert about this →
What's the difference between Metal Up, Light Body Work, and Scuff & Shoot?

Metal Up: Stripped to bare metal and restored from scratch — full primer, sealer, basecoat, clearcoat. Best for complete restorations.
Light Body Work: Vehicle is overall in good shape but has some areas needing filler and spot priming before paint.
Scuff & Shoot: Vehicle is in mint condition or it's a budget/quick build — just scuff the existing finish and paint over it. No body work or heavy primer needed.

Ask the paint expert about this →
What's the difference between OEM and Custom Color kits?

OEMatch Kits: Factory-matched colors for 100+ makes. Perfect for matching your vehicle's original color. 2-stage and 3-stage options available. Note: all OEM colors should be blended into surrounding panels since original paint fades over time.
Custom Color Kits: Colorshifts, candies, metallics, pearls, and solid colors — unique finishes you won't find at a body shop counter. Choose from 500+ options.

Ask the paint expert about this →
Why does the temperature setting matter?

Temperature determines which reducer and activator/hardener speed goes in your kit. The wrong speed can cause solvent pop, runs, or poor adhesion. Choose the approximate temperature you plan to be painting in — time of year, time of day, and the building you're spraying in all matter. Most projects are sprayed in 71–90°F. Reducer guide: AR-3060 (Fast, below 65°F), AR-3070 (Medium, 65–80°F), AR-3080 (Slow, 80–90°F), AR-3090 (Extra Slow, 90°F+).

Ask the paint expert about this →
Do I need a spray gun? What kind?

Yes — you need an HVLP spray gun with a 1.3–1.4mm nozzle for basecoat and clearcoat. For high-build primer, use a 1.8–2.0mm nozzle. You also need an air compressor: 12+ CFM at 40 PSI, 60 gallon tank minimum (30 gallon bare minimum for panels only). Must have a moisture separator and water trap. We sell spray guns and equipment if you need them.

Ask the paint expert about this →
Can I choose any color?

Absolutely! Select from 500+ colors including custom, OEM factory-match, candy, metallic, pearl, colorshift, and solid options. We also offer tri-stage colors that include the required undercoat automatically.

Ask the paint expert about this →
What are the mix ratios for the products in my kit?

AP-7541 DTM Primer: 4:1:2 as a no-sand sealer, or 4:1:1 as a high-build primer (primer : activator : reducer)
Alpha Basecoat: 1:1 (basecoat : reducer) — no hardener in basecoat
AC-4521 HS Glamour Clearcoat: 2:1 (clearcoat : activator, no reducer needed)
Full details on the included cheat sheet and on our Tips & Tricks page.

Ask the paint expert about this →
Should I order a painted sample first?

For custom colors, yes — order a painted sample and look at it in sunlight, shade and under shop lights before committing to a full kit. OEM colors are mixed to your factory paint code and blended into the surrounding panels, so a sample isn't needed. Shop painted samples.

Ask the paint expert about this →
What if I'm a complete beginner — can I still do this?

Yes! Our kits are designed for first-time painters. We include step-by-step instructions, a downloadable cheat sheet, and have dozens of tutorial videos on our YouTube channel. Our customer service team is available by phone, text, email, and chat to walk you through every step. 25,000+ paint jobs have been completed with our kits — many by people who had never sprayed paint before.

Ask the paint expert about this →
What's a tri-stage color and do I need an undercoat?

Tri-stage colors (like certain pearls, candies, and OEM colors) require a specific undercoat sprayed underneath the basecoat for the correct color match. Don't worry — our website automatically detects tri-stage colors and prompts you to add the undercoat. Ground coat options: Black, White, Grey, or Iris Smoke depending on the color.

Ask the paint expert about this →
Can I use spray cans instead of a spray gun?

Yes — we offer the same Alpha formulas in aerosol cans. Great for wheels, bumpers, panels, helmets, and small projects. Our 2K clearcoat cans have a 24–48 hour pot life after activation. You can wet sand and polish spray can clear just like spray gun application. Shop Spray Cans.

Ask the paint expert about this →
Do you ship paint internationally?

Paint (hazmat) ships to US, Canada, and Mexico only via UPS Ground. Non-hazmat items (painted samples, pigments, tools, merch) ship worldwide. Standard processing is 1–2 business days, mixed paint orders take 3–4 days.

Ask the paint expert about this →
What's the return policy on paint kits?

Unopened/unmixed products can be returned within 10 days. Opened, used, or mixed paint cannot be returned. We charge a 2.5% purchase fee + 2.5% refund processing fee on returns. After 10 days it's case-by-case with a 10% restocking fee + return shipping. We also offer order protection (third-party shipping insurance) at checkout.

Ask the paint expert about this →
How do I contact you for help with my project?

We're here every step of the way! Chat: bottom-right of this page. Call/Text: 508-316-9868. Email: help@thespraysource.com. Our full-time customer service team handles calls, texts, emails, chats, and social media messages.

Ask the paint expert about this →
How many coats of basecoat do I need?

Most colors require 2-4 coats. Lighter colors and metallics may need more. Apply medium wet coats (0.8-1.2 mil / 20-30 microns each). Check color coverage between coats — the surface should look uniform with no primer showing through.

Ask the paint expert about this →
How long should I wait between coats?

Allow each basecoat to flash dry (5-15 minutes at 68°F — the surface turns matte) before applying the next coat. Wait 45 minutes after the final basecoat before applying clearcoat. For clearcoat, wait 8-10 minutes between coats (fingerprint tacky).

Ask the paint expert about this →
What spray gun settings should I use?

Basecoat: HVLP 25-30 PSI at the cap, 1.3-1.4mm nozzle. Clearcoat: HVLP 30-35 PSI, 1.3-1.4mm nozzle. Primer (sealer): 1.3-1.4mm nozzle. Primer (high build): 1.7-2.0mm nozzle at 35-40 PSI. Hold the gun 6-8 inches from the surface and overlap each pass 50-75%. Keep the gun perpendicular — don't arc or fan.

Ask the paint expert about this →
Do I need anything else besides the kit?

The kit includes everything from primer to clearcoat. The only things you may need separately are prep supplies: masking tape & paper, body filler (if doing bodywork), sandpaper, scuff pads, wax & grease remover, and tack cloths. These are available as optional add-ons in the Kit Builder.

Ask the paint expert about this →
What's the difference between Full Color Change and Exterior Panels Only?

Full Color Change covers the entire exterior including door jambs, engine bay, trunk jambs — everything visible when doors are open. Exterior Panels Only covers just the outside panels, NOT door jambs or engine bay. Full Color Change requires more product and more masking work.

Ask the paint expert about this →
What if my basecoat sits for more than 8 hours without clearcoat?

If the basecoat sits for more than 8 hours without clearcoat, you must scuff the surface with 600-800 grit sandpaper and ensure a matte finish before recoating or applying clearcoat. This ensures proper adhesion of the clearcoat layer.

Ask the paint expert about this →
How long until I can wet sand and polish the clearcoat?

Wait at least 12 hours for assembly, polishing, and recoating. For wet sanding and polishing, use P1200-P5000 grit in progressive steps, then compound and polish for a mirror finish. For recoating or flowcoat, sand with P600-P800.

Ask the paint expert about this →
My paint has orange peel (rough, bumpy texture). What happened?

Common causes: gun held too far from the surface, air pressure too low, paint too thick (not enough reducer), wrong reducer speed, or material not mixed well. Fix: let cure fully, wet sand with 1500-2000 grit, then compound and polish. Prevention: hold gun 6-8 inches from surface, use 26-29 PSI for HVLP, mix basecoat 1:1 with reducer, choose the right reducer speed for your temp.

Ask the paint expert about this →
I'm seeing fisheyes (small craters) in my paint. What do I do?

Fisheyes are caused by surface contamination — silicone, wax, grease, oil, or polish residue. They cannot be buffed out. The affected area must be sanded back completely and repainted. Prevention: wipe the entire surface with wax and grease remover before every step, use clean filtered compressed air, and keep silicone-based products away from the spray area entirely.

Ask the paint expert about this →
Can I mix activated (mixed) paint back into the original can?

Absolutely NOT. If a product is activated (mixed with hardener), it cannot go back into the original container — otherwise it will activate the entire product and it will harden and go bad. Only mix what you can spray within the pot life window.

Ask the paint expert about this →
